Anti-Decubitus Air Mattress (AMR5000)

Ripples Mattress Advance is a valuable overlay system designed for prevention and treatment of patients at low to medium risk of pressure ulcers. By having a series of individual cells inflate and deflate alternatively cycles, the pressure is periodically redistributed by inflating and deflating cells in order to mimic natural sleep movement patterns and avoid long term pressurization of tissue.

1-in-3 Alternating Overlay System
Inflating and deflating every 12 minutes between A, B, C which equals to manually turn over the patient on bed for 5 times in 1 hour.

Pump

Dimension	27.5(L) x 13.5(W) x 9(H)cm
Weight	1.6kg
Case Material	Flame Retardant ABS
Supply Voltage	AC 110V / AC 220V, 50 Hz / 60 Hz
Operating Cycle	12 Min

Mattress

Dimension	190(L) x 85(W) x 11.5(H)cm
Alternating	1 – IN – 2
Cell Height	4.5” x 17 Cells
Weight	6.5kg
Material	Nylon PU (Cover) / Nylon PVC (Cell)
Maximum Patient Weight	150kg
Test Duration	24 Hours (Inflation)

*The airflow output cycle time may vary slightly due to different electrical voltage and frequency
*Mattress should always be used directly on top of an existing surface or an additional foam
